Detachable cable for full flexibility and investment security. |
CMOS APS technology for high image quality. |
Rounded edges and optimal cable location for comfortable positioning. |
![]() |
CMOS APS (Active Pixel Sensor) technology delivers sharp, low noise, high resolution images which show even the smallest details to aid accurate diagnosis. |
An optimally locatedsensor cable interface means simple sensor positioning. Patients will appreciate the rounded edges that make sensor placement more comfortabe. |
![]() |
![]() |
The sensor with its cable as well as the PC USB cable can be detached from the CDR box allowing thereby by full flexibility, making your investment a secure one. |
| TECHNICAL SPECIFICATIONS | |||
| Size | Sensor Size 0 | Sensor Size 1 | Sensor Size 2 |
| Technology | CMOS APS (Active Pixel Sensors) | ||
| Signal-to-Noise Ratio | 120 : 1 | ||
| Sensor thickness | < 5 mm | ||
| Interface | High Speed USB 2.0 | ||
| Sensor Cable length | 1.80 m | ||
| External dimensions | 31x22 mm | 37x24 mm | 43x30 mm |
| Active sensor area | 24x18 mm | 30x20 mm | 36x26 mm |
| USB Cable length | 5m | ||
