Thanks to its 445 nm wavelength, with higher absorption in haemoglobin, cutting is faster and requires much less power. Result is treatment with minimised thermal dafage and increased efficiency. |
Aquamarine can be used for variety of treatments in soft tissue surgery, periodontology, endodontics and haemostasis. In addition, it can be used for single tooth whitening and as treatment option for a variety of indications. |
The diode laser operates at a wavelength absorbed by the soft tissue more efficiently, resulting in more precise cutting and faster healing thus increasing patient comfort. The focused beam treats the affected area efficiently and in less time. |
![]() |
![]() |
![]() |
Laser allows for almost bloodless surgical procedures to be performed more efficiently with less pain and higher visibility. Due to low energy and 445nm wavelength used by Aquamarine, carbonisation and thermaldamage to surrounding tissue are minimised, while cutting is faster. |
Aquamarine can also be used as supplementary therapy for improved germ and bacteria reduction |
Aquamarine can also be used as supplementary therapy for improved germ and bacteria reduction |
Aquamarine is highly effective in direct haemostasis. Thanks to the peak absorbtion in the haemoglobin, its 445nm wavelength is highly efficient. |
As an added benefit, Aquamarine can be used for single tooth whitening. Best used with blue or yellow gel, the results surpass alternative treatments available. |
TECHNICAL SPECIFICATION | |
Wavelength | 445 +/-10 nm |
Power | 0.2- 1.4 W CW (in 0.1 W steps) |
Pilot Beam | 638 +/-10 nm, ≤ 5 mW |
Operation modes | CW, Chopped Mode |
Frequency | 10 - 200 Hz (in 10 Hz steps) |
Duty cycle | 10 - 100% (in 10% steps) |
Battery | Lithium Ion |
Battery working time | 1 hour with full power |
Recharge time | 3 hours when battery is empty |
Use interface | Touchscreen |
Laser activation | Finger switch |
Fibre management | Sterile -single-use fiber tips (UniTip 320 μm and EndoTip 200 μm) Autoclavable glass rod (ActiveTip 8 mm) |
Goggles | Multi-Wavelength Goggles (445 nm, 660 nm, 970 nm) |
Software | Preset for surgery, endo. germ reduction, perio. germ reduction & haemostasis |
Software connections | 12 free programmable own programs for each user 2 individual user profiles with own pin codes (Admin can define password, max. power, applications and right to change preset for second user) |
