  • HIGHLIGHTS
  • TREATMENT ADVANTAGES
  • TECHNICAL SPECIFICATION



  Cutting fast with minimum power

Thanks to its 445 nm wavelength, with higher absorption in haemoglobin, cutting is faster and requires much less power. Result is treatment with minimised thermal dafage and increased efficiency.

  Wide range of treatments

Aquamarine can be used for variety of treatments in soft tissue surgery, periodontology, endodontics and haemostasis. In addition, it can be used for single tooth whitening and as treatment option for a variety of indications.

  Enhanced patient comfort

The diode laser operates at a wavelength absorbed by the soft tissue more efficiently, resulting in more precise cutting and faster healing thus increasing patient comfort. The focused beam treats the affected area efficiently and in less time.







  Sugery

Laser allows for almost bloodless surgical procedures to be performed more efficiently with less pain and higher visibility. Due to low energy and 445nm wavelength used by Aquamarine, carbonisation and thermaldamage to surrounding tissue are minimised, while cutting is faster.

  Periodontology

Aquamarine can also be used as supplementary therapy for improved germ and bacteria reduction
in the periodontal pocket in addition to conventional scaling and root planning.

  Endodontics

Aquamarine can also be used as supplementary therapy for improved germ and bacteria reduction
in the periodontal pocket in addition to conventional scaling and root planning.

  Haemostasis

Aquamarine is highly effective in direct haemostasis. Thanks to the peak absorbtion in the haemoglobin, its 445nm wavelength is highly efficient.

  Whitening

As an added benefit, Aquamarine can be used for single tooth whitening. Best used with blue or yellow gel, the results surpass alternative treatments available.





TECHNICAL SPECIFICATION
Wavelength 445 +/-10 nm
Power 0.2- 1.4 W CW (in 0.1 W steps)
Pilot Beam 638 +/-10 nm, ≤ 5 mW
Operation modes CW, Chopped Mode
Frequency 10 - 200 Hz (in 10 Hz steps)
Duty cycle 10 - 100% (in 10% steps)
Battery Lithium Ion
Battery working time 1 hour with full power
Recharge time 3 hours when battery is empty
Use interface Touchscreen
Laser activation Finger switch
Fibre management Sterile -single-use fiber tips (UniTip 320 μm and EndoTip 200 μm)
Autoclavable glass rod (ActiveTip 8 mm)
Goggles Multi-Wavelength Goggles (445 nm, 660 nm, 970 nm)
Software Preset for surgery, endo. germ reduction, perio. germ
reduction & haemostasis
Software connections 12 free programmable own programs for each user 2 individual user
profiles with own pin codes (Admin can define password, max. power,
applications and right to change preset for second user)
